Запчасти Komatsu PC350LC-8M0 ГИДР. БАК. (№8-) ГИДР. БАК.

1

207-60-77111

Tank

2

203-60-31100

Elbow Assembly

3

203-60-31160

Tube

4

07044-12412

Plug

5

07002-12434

O-ring

6

02783-10628

Elbow

7

07002-12434

O-ring

8

02896-11018

O-ring

9

02782-10315

Elbow

10

07002-12034

O-ring

11

02896-11009

O-ring

12

21W-62-42640

Elbow

13

07002-13334

O-ring

14

207-62-64740

O-ring

15

02782-10422

Elbow

16

07002-12034

O-ring

17

02896-11012

O-ring

18

02782-10311

Elbow

19

07002-11423

O-ring

20

02896-11009

O-ring

21

207-60-71183

Element

22

20Y-60-31140

Strainer

23

20Y-60-31450

Valve Assembly

24

20Y-60-21240

Spring

25

207-60-77131

Cover

26

07000-15195

O-ring

27

01010-81225

Bolt

28

01643-31232

Washer

|$28

207-60-75120

Strainer Assembly

29

208-60-71150

Rod Assembly

30

12R-60-11230

Spring

31

20Y-60-21320

Holder

32

22B-60-11160

Strainer

33

207-60-77150

Cover

34

07000-15160

O-ring

35

01010-81225

Bolt

36

01643-31232

Washer

37

17A-60-11310

Cap Assembly

38

20Y-60-21470

Element

39

208-60-71181

Filler Neck

40

20Y-60-21340

Gasket

41

01252-70516

Bolt

42

01601-20513

Washer

43

07285-00200

Clip, Hose

44

07261-21415

Hose

45

07056-10045

Strainer

46

04065-04718

Ring, Snap

46

20Y-60-31271

Breather Assembly

47

207-60-51311

Element

48

207-60-51320

Seal

49

Body

50

Cover

51

Nut

52

Nut

53

Packing

54

01252-70516

Bolt

55

01601-20513

Washer

56

20Y-00-42110

Plate

57

01010-81635

Bolt

58

01643-31645

Washer

59

195-03-11570

Shim, T=1.0mm
