Запчасти Komatsu PC350LC-8 SUPER LONG FRONT ЦИЛИНДР КОВША

|1

707-01-0H920

CYLINDER ASSEMBLY

1

707-13-13880

CYLINDER

2

707-76-80431

BUSHING

3

07145-00080

SEAL, DUST (KIT)

4

707-58-90E60

ROD, PISTON

5

707-76-80020

BUSHING

6

20Y-70-23230

SEAL, DUST (KIT)

7

707-27-13750

HEAD, CYLINDER

8

07179-13104

RING, SNAP

9

195-63-94170

SEAL, DUST (KIT)

10

707-52-90680

BUSHING

11

707-75-90110

RING, SNAP

12

707-51-90030

PACKING, ROD (KIT)

13

07000-15120

O-RING (KIT)

14

707-35-91320

RING, BACK-UP (KIT)

15

707-51-90650

RING, BUFFER (KIT)

16

01010-81875

BOLT

17

707-41-11840

WASHER

18

707-36-13780

PISTON

19

707-44-13150

RING, PISTON (KIT)

20

707-39-13150

RING, WEAR (KIT)

21

707-44-13911

RING

22

707-35-90940

RING, BACK-UP (KIT)

23

07000-15080

O-RING (KIT)

24

01310-01216

SCREW

25

07020-00000

FITTING,GREASE

26

707-86-67820

TUBE

27

07372-21060

BOLT

28

01643-51032

WASHER

29

07372-21045

BOLT

30

01643-51032

WASHER

31

07000-13030

O-RING (KIT)

32

707-88-22640

BRACKET

33

707-88-21331

BAND

34

07372-21035

BOLT

35

01643-51032

WASHER

36

07283-32738

CLIP

37

01597-01009

NUT

38

01643-31032

WASHER

39

707-88-33030

HEAD

40

07371-30640

FLANGE, SPLIT

41

07372-21035

BOLT

42

01643-51032

WASHER

|$44

707-98-47720

SERVICE KIT
