Запчасти Komatsu PC350LC-8 МОТОР ПОВОРОТА (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

706-7K-01170

MOTOR ASSEMBLY

|1

706-7K-01040

MOTOR ASSEMBLY

1

706-7K-03140

MOTOR SUB ASSEMBLY

1

706-7K-03030

MOTOR SUB ASSEMBLY

1

706-7K-41150

CASE, MOTOR

2

706-7K-71110

HOUSING

3

706-7K-40010

BEARING

4

706-75-42830

PIN, DOWEL

5

706-77-72280

PLUG

6

07002-62034

O-RING

|6

07002-12034

O-RING

7

709-74-92810

VALVE

8

709-75-92220

SPRING

9

709-74-92821

PLUG

10

708-2L-23960

O-RING

|10

700-93-11320

O-RING

11

700-93-11330

RING, BACK-UP

12

706-77-72130

VALVE

13

706-77-72140

SPRING

14

706-77-72150

PLUG

15

07002-64234

O-RING

|15

07002-14234

O-RING

16

706-7K-40040

O-RING

|16

706-7K-40020

O-RING

17

01252-61450

BOLT
