Запчасти Komatsu PC350LC-8 ЦИЛИНДР РУКОЯТИ(№K-K9) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XZ981

CYLINDER GROUP, (FINAL COATING)

1

707-01-0A451

ARM CYLINDER ASSEMBLY

1

707-13-16710

CYLINDER

2

707-76-10290

BUSHING

3

07145-00100

SEAL, DUST (KIT)

4

707-58-11360

ROD

5

707-76-10290

BUSHING

6

07145-00100

SEAL, DUST (KIT)

7

707-71-32800

COLLAR

8

707-35-91640

RING, BACK-UP (KIT)

9

07000-15150

O-RING (KIT)

10

707-71-61130

PLUNGER

11

707-71-70290

PLUNGER

12

04260-00635

BALL

13

707-71-91270

CAP

14

07020-00000

FITTING, GREASE

15

707-27-16920

HEAD

16

198-63-94170

SEAL, DUST (KIT)

17

07179-13126

RING, SNAP

18

707-52-90850

BUSHING

19

707-51-11030

PACKING, ROD (KIT)

20

707-51-11640

RING, BUFFER (KIT)

21

707-35-91640

RING, BACK-UP (KIT)

22

07000-15150

O-RING (KIT)

23

01010-82085

BOLT

24

707-88-75310

WASHER

25

707-36-16580

PISTON

26

01310-01216

SCREW

27

707-44-16180

RING, PISTON (KIT)

28

707-39-16120

RING, WEAR (KIT)

29

707-44-16910

RING

30

07001-05100

RING, BACK-UP (KIT)

31

07000-15100

O-RING (KIT)

32

707-83-13010

VALVE

33

07750-01628

SPRING

34

707-87-14070

PLUG

35

07002-12034

O-RING (KIT)

36

707-86-11600

TUBE

37

707-86-11610

BLOCK

38

07372-21060

BOLT

39

01643-51032

WASHER

40

01010-81095

BOLT

41

01643-31032

WASHER

42

07000-13035

O-RING (KIT)

43

707-88-22740

BRACKET

44

707-88-21380

BAND

45

207-63-64190

BRACKET

46

707-88-21390

BAND

47

07372-21240

BOLT

48

01643-51232

WASHER

49

07283-33442

CLIP

50

01643-31032

WASHER

51

01597-01009

NUT

52

707-88-33040

CAP

53

07371-31049

FLANGE, SPLIT

54

07372-21035

BOLT

55

01643-51032

WASHER

K

707-99-72300

SERVICE KIT
