Запчасти Komatsu PC350LC-8 ОСНОВН. НАСОС (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2G-00150

PUMP ASSEMBLY

|1

708-2G-00700

PUMP ASSEMBLY

1

702-21-57400

PILOT VALVE

|1

702-21-57600

PILOT VALVE

2

723-11-19960

O-RING

3

702-21-54910

O-RING

4

01252-60635

BOLT

5

20Y-62-22790

BAND RED

6

702-21-57500

PILOT VALVE

7

723-11-19960

O-RING

8

702-21-54910

O-RING

9

702-16-55260

BOLT

10

20Y-62-22830

BAND WHITE

|11

702-21-56600

VALVE ASSEMBLY

11

702-21-55920

PLUG

12

702-21-55930

PISTON

13

702-21-56610

SPRING

14

702-21-55951

BLOCK

15

07002-12034

O-RING

16

07000-11008

O-RING

17

722-12-18240

O-RING

18

01252-60530

BOLT

19

708-2G-15680

PLUG

20

07000-B1008

O-RING

21

07001-01008

RING

22

07002-61423

O-RING

23

01643-51232

WASHER

24

01010-81220

BOLT

25

08193-21012

CLIP

26

708-2G-19130

SPACER

27

01010-81235

BOLT

28

04434-50612

CLIP
