Запчасти Komatsu PC350LC-8 ОСНОВН. НАСОС (7/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2G-00150

PUMP ASSEMBLY

|1

708-2G-00700

PUMP ASSEMBLY

|1

708-2G-01150

PUMP SUB ASSEMBLY

|1

708-2G-01070

PUMP SUB ASSEMBLY

1

708-2G-12650

SHAFT

|1

708-2G-12190

SHAFT

2

708-2G-12251

BEARING

3

708-2G-05010

WASHER KIT

3

WASHER 3.0MM

3

WASHER 3.1MM

3

WASHER 3.2MM

4

708-1F-12270

RING, SNAP

|5

708-2G-04270

BLOCK ASSEMBLY, REAR

5

BLOCK, CYLINDER

6

PLATE, VALVE

7

708-18-13230

PIN

8

04065-05520

RING, SNAP

9

708-2G-13131

SEAT

10

708-2G-13152

SPRING

11

708-2G-13141

SEAT

12

708-2G-13510

GUIDE, RETAINER

13

708-2H-23360

PIN

14

708-2G-13341

RETAINER, SHOE

|15

708-2G-13810

PISTON SUB ASSEMBLY

15

708-2G-13370

PISTON SUB ASSEMBLY

|16

708-2G-04670

CRADLE SUB ASSEMBLY

|16

708-2G-04670

CRADLE SUB ASSEMBLY

16

CRADLE

17

CAM, ROCKER

18

04020-01434

PIN, DOWEL

19

07000-B1009

O-RING

20

01252-61230

BOLT
