Запчасти Komatsu PC350LC-8 ОСНОВН. НАСОС (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2G-00150

PUMP ASSEMBLY

|1

708-2G-00700

PUMP ASSEMBLY

|1

708-2G-01150

PUMP SUB ASSEMBLY

|1

708-2G-01070

PUMP SUB ASSEMBLY

1

708-2G-14120

SLIDER

|2

708-2G-03640

VALVE ASSEMBLY

|2

708-2G-03580

VALVE ASSEMBLY, PC

|2

708-2G-03650

PISTON ASSEMBLY

|2

708-2G-03590

PISTON ASSEMBLY, SERVO

2

PISTON, SERVO

3

SCREW

4

SEAL

|4

708-2G-15320

SEAL

5

PLUG

|5

708-2G-15221

PLUG

6

708-2L-35760

BALL

7

708-2L-35770

PLUG

8

SEAL

|8

708-2L-35690

SEAL

9

708-2L-35170

PIN

10

708-2G-15211

SPOOL

11

708-2G-15290

RETAINER

12

708-2G-15140

SEAT

13

708-2G-15270

SPRING

14

708-2G-15280

SPRING

15

708-2G-15151

SEAT

16

708-2G-15250

SPRING

17

708-2G-14340

SCREW

18

07000-B3038

O-RING

19

708-2G-15230

RING, BACK-UP

20

SEAL

|20

708-2G-15260

SEAL

21

708-2G-15240

PLUG

22

07000-B2012

O-RING

23

07000-B2050

O-RING

24

708-2G-15310

RING

25

708-2G-14190

COVER

26

01580-10806

NUT

27

708-2L-35290

NUT

28

708-2G-15330

RING, WIRE

29

01252-61645

BOLT
