Запчасти Komatsu PC350LC-8 ОСНОВН. НАСОС (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2G-00150

PUMP ASSEMBLY

|1

708-2G-00700

PUMP ASSEMBLY

|1

708-2G-01150

PUMP SUB ASSEMBLY

|1

708-2G-01070

PUMP SUB ASSEMBLY

1

708-2G-12640

SHAFT

|1

708-2G-12180

SHAFT

2

708-2G-12251

BEARING

3

708-2G-05010

WASHER KIT

3

WASHER 3.0MM

3

WASHER 3.1MM

3

WASHER 3.2MM

4

708-1F-12270

RING, SNAP

5

708-2G-12230

SEAL, OIL

|5

708-2G-12220

SEAL, OIL

6

708-8H-32160

SPACER

7

04065-07825

RING, SNAP

|8

708-2G-04710

CYLINDER BLOCK ASSEMBLY

|8

708-2G-04260

CYLINDER BLOCK ASSEMBLY

8

BLOCK, CYLINDER

9

PLATE, VALVE

10

708-18-13230

PIN

11

04065-05520

RING, SNAP

12

708-2G-13131

SEAT

13

708-2G-13152

SPRING

14

708-2G-13141

SEAT

15

708-2G-13510

GUIDE, RETAINER

16

708-2H-23360

PIN

17

708-2G-13341

RETAINER, SHOE

18

708-2G-13810

PISTON SUB ASSEMBLY

|18

708-2G-13370

PISTON SUB ASSEMBLY

|19

708-2G-04670

CRADLE SUB ASSEMBLY

|19

708-2G-04670

CRADLE SUB ASSEMBLY

19

CRADLE

20

CAM, ROCKER

21

04020-01434

PIN, DOWEL

22

07000-B1009

O-RING

23

01252-61230

BOLT
