Запчасти Komatsu PC350LC-8 1-Я СТРЕЛА ЦИЛИНДР (/) (2-СЕКЦИОНН. СТРЕЛА) (№K8-) T РАБОЧЕЕ ОБОРУДОВАНИЕ

G-1

707-01-0ZM50

CYLINDER GROUP, (FINAL COATING)

|1

707-01-0AR60

CYLINDER ASSEMBLY

1

707-13-14990

CYLINDER

2

707-76-90490

BUSHING

3

07145-00090

SEAL, DUST

4

707-58-10900

ROD, PISTON

5

707-76-10290

BUSHING

6

07145-00100

SEAL, DUST

7

707-27-14890

HEAD, CYLINDER

8

07179-13114

RING, SNAP

9

176-63-56170

SEAL, DUST

10

707-52-90781

BUSHING

11

707-51-10030

PACKING, ROD

12

07000-15130

O-RING

13

707-35-91420

RING, BACK-UP

14

707-51-10640

RING, BUFFER

15

01010-81875

BOLT

16

707-41-11840

WASHER

17

707-36-14650

PISTON

18

707-44-14180

RING, PISTON

19

707-39-14110

RING, WEAR

20

707-44-14910

RING

21

707-71-61090

PLUNGER

22

707-71-35120

COLLAR

23

707-35-91420

RING, BACK-UP

24

07000-15130

O-RING

25

07001-05090

RING

26

07000-15090

O-RING

27

01310-01216

SCREW

28

07043-00108

PLUG

29

707-75-10160

RING, SNAP

30

707-88-33040

CAP

31

07371-31049

FLANGE, SPLIT

32

07372-21035

BOLT

33

01643-51032

WASHER

K

707-99-58080

SERVICE KIT
