Запчасти Komatsu PC350LC-8 БЫСТРОСЪЕМН. МЕХ-М ЛИНИЯ (PPC ТРУБЫ) ( АКТУАТОР) (№K8-) H ГИДРАВЛИКА

1

02760-002A3

HOSE

2

02760-00204

HOSE

3

02760-00208

HOSE 800MM

4

02760-002A8

HOSE

5

08034-20519

BAND

6

20Y-62-22810

BAND YELLOW

7

20Y-62-22840

BAND BLACK

8

20Y-62-22860

BAND BROWN

9

02760-00213

HOSE

10

207-62-72640

HOSE 1400MM

11

20Y-62-22790

BAND RED

12

02760-00204

HOSE

13

04435-51512

CLIP

14

195-01-16261

COLLAR

15

01011-81240

BOLT

16

01643-31232

WASHER

17

04434-52512

CLIP

18

207-62-73370

HOSE 1800MM

19

20Y-62-22810

BAND YELLOW

20

20Y-62-42510

HOSE 1500MM

21

207-62-73370

HOSE 1800MM

22

20Y-62-22840

BAND BLACK

23

20Y-62-22860

BAND BROWN

24

20Y-62-42510

HOSE 1500MM

25

08034-20519

BAND

26

08034-20310

BAND

27

02781-0021D

UNION

28

07002-11423

O-RING

29

02896-11008

O-RING

30

20Y-62-43430

BLOCK

31

20Y-62-43450

PLATE

32

01010-80830

BOLT

33

01643-30823

WASHER

34

14X-43-14840

ELBOW

35

201-60-11390

O-RING

36

20Y-62-19560

O-RING

37

20Y-62-22271

ELBOW

38

201-60-11390

O-RING

39

20Y-62-19560

O-RING

40

07002-11423

O-RING

41

206-06-61130

SWITCH
