Запчасти Komatsu PC350LC-8 СИСТЕМА ОХЛАЖДЕНИЯ РАДИАТОР И МАСЛООХЛАДИТЕЛЬ (№B-) СИСТЕМА ОХЛАЖДЕНИЯ

1

207-03-75121

Radiator

2

20Y-03-22110

Cap

3

205-03-71230

Hose

4

20Y-03-11330

Clip

5

205-03-62660

Plug

6

07000-11007

O-ring

7

208-03-71731

Seal

8

208-03-71810

Seal

9

208-03-71840

Seal

10

207-03-76450

Bracket

11

01010-81235

Bolt

12

01643-31232

Washer

13

14X-03-51640

Spacer

14

14X-03-51621

Cushion

15

14X-03-51770

Washer

16

01010-81045

Bolt

|16

01010-81055

Bolt

17

01643-31032

Washer

18

207-03-75171

Frame

19

207-03-75181

Frame

20

207-03-76341

Frame

21

01010-81225

Bolt

22

01643-31232

Washer

23

207-03-76350

Frame

24

01010-81030

Bolt

25

01643-31032

Washer

26

01010-81020

Bolt

27

01643-31032

Washer

28

22B-03-12590

Cushion

29

208-03-71380

Cushion

30

208-03-71480

Seal

31

208-03-71490

Seal

32

208-03-71780

Seal

33

207-03-76410

Seal

34

208-03-71821

Seal

35

208-03-71830

Seal

36

207-03-76320

Oil Cooler Assembly

37

207-03-76330

Frame

38

207-03-76380

Seal

39

207-03-76390

Seal

40

207-03-76420

Seal

41

208-03-71131

Oil Cooler

42

208-03-71690

Seal

43

208-03-71850

Seal

44

208-03-71860

Seal

45

208-03-71870

Seal

46

208-03-71890

Seal

47

01010-81020

Bolt

48

01643-31032

Washer

49

01010-81240

Bolt

50

01643-31232

Washer

51

07000-13045

O-ring

52

01010-81030

Bolt

53

01643-31032

Washer

54

01010-81225

Bolt

55

01643-31232

Washer
