Запчасти Komatsu PC350LC-8 РУКОЯТЬ, .M, УСИЛ.ENED, ЧАС. СИСТ. СМАЗКИ ТИП, ЦИЛИНДР КОВША РУКОЯТЬ, .M, УСИЛ.ENED, ЧАС. СИСТ. СМАЗКИ ТИП

|1

707-01-0C622

Cylinder Assembly

1

707-13-15261

Cylinder

2

707-76-90130

Bushing

3

07145-00090

Seal, Dust, (Kit : K12)

4

07020-00000

Fitting, Grease

5

707-58-11370

Rod

6

207-63-76170

Bushing

7

207-70-72120

Seal, Dust, (Kit : K12)

8

07020-00000

Fitting, Grease

9

707-27-15650

Head

10

198-63-94170

Seal, Dust, (Kit : K12)

11

07179-13126

Ring, Snap

12

707-52-90850

Bushing

13

707-75-11040

Ring, Snap

14

707-51-11030

Packing, Rod, (Kit : K12)

15

707-51-11640

Ring, Buffer, (Kit : K12)

16

707-35-91660

Ring, Back-up, (Kit : K12)

17

07000-15140

O-ring, (Kit : K12)

18

01010-82085

Bolt

19

707-88-75310

Washer

20

707-36-15260

Piston

21

01310-01216

Screw

22

707-44-15180

Ring, Piston, (Kit : K12)

23

707-39-15110

Ring, Wear, (Kit : K12)

24

707-44-15911

Ring

25

07001-05100

Ring, Back-up, (Kit : K12)

26

07000-15100

O-ring, (Kit : K12)

27

707-86-11631

Tube

28

207-63-73180

Tube

29

07372-21060

Bolt

30

01643-51032

Washer

31

07000-13035

O-ring, (Kit : K12)

32

707-88-22690

Bracket

33

707-88-21420

Band

34

07372-21240

Bolt

35

01643-51232

Washer

36

707-88-10150

Clamp

37

01010-81245

Bolt

38

01643-31232

Washer

39

707-88-33040

Cap

40

07371-31049

Flange

41

07372-21035

Bolt

42

01643-51032

Washer
