Запчасти Komatsu PC350LC-8 СТАРТЕР, KW СТАРТЕР, KW

Схема запчастей Komatsu PC350LC-8 - СТАРТЕР, KW СТАРТЕР, KW
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
28
27
29
31
28
30
37
46
41
36
35
46
34
38
33
50
45
25
49
43
44
26
50
1
2
3
4
3
5
40
39
32
42
48
47

Артикул

Название

Примечание

Количество

|1

600-863-8112

Starting Motor Assembly, 11Kw

1

KD1-09279-0090

Nut

2

KD1-0335-08002

Washer, Spring

3

KD1-0330-08022

Washer, Plain

4

KD1-0345-08001

Washer, Seal

5

KD0-23303-0020

Pin, Lever

6

KD1-23914-0020

Ring

7

KD1-23181-0020

Stopper

8

KD0-23120-0180

Shaft Assembly

9

KD0-23310-1740

Bracket Assembly

10

KD1-23500-0970

Clutch Assembly, Over Running

11

KD1-23320-0290

Lever Assembly

12

KD0-09201-0850

Bearing, Ball

13

KD0-23600-0410

Bracket Assembly

14

KD0-23611-1101

Bracket

15

KD0-0274-06202

Bolt

16

KD1-23951-0051

Packing

17

KD1-0400-30100

Pin, Straight

18

KD0-23100-0430

Armature Assembly

19

KD0-47100-4651

Switch Assembly, Magnetic

20

KD0-23200-0671

Yoke Assembly

21

KD0-09271-3620

Name Plate

22

KD1-09211-1120

O-ring

23

KD0-23740-0351

Brush Assembly

24

KD0-23750-0490

Holder Assembly, Brush

25

KD0-47761-2681

Cover

26

KD0-47761-2691

Cover

27

KD0-09011-3140

Screw

28

KD1-09211-0081

O-ring

29

KD0-23710-0221

Bracket, Rear

30

KD0-09001-4380

Bolt

31

KD1-47921-0790

Washer, Insulate

32

KD0-0276-08402

Bolt

33

KD0-09057-0110

Washer

34

KD1-23941-0040

Washer, Insulate

35

KD1-23921-0140

Washer

36

KD1-23921-0130

Washer

37

KD0-0055-05082

Screw

38

KD0-09057-0190

Washer

39

KD0-0020-05062

Screw

40

KD1-0345-05001

Washer, Seal

41

KD1-0240-06305

Bolt

42

KD0-25000-8521

Switch Assembly

43

KD0-0270-06602

Bolt

44

KD0-47927-1390

Holder

45

KD0-47761-2671

Cover

46

KD1-09211-0981

O-ring

47

KD0-09006-0660

Nut

48

KD0-09006-0670

Nut

49

KD1-09257-0050

Band

50

KD0-09275-1430

Plate, Caution

Выбрано товаров: 51
