Запчасти Komatsu PC350LC-8 ГЕНЕРАТОР, AMP. (/) ГЕНЕРАТОР, AMP.

|1

600-861-6110

Alternator, 60Amp.

1

KD0-35100-0300

Rotor Assembly

2

KD1-33923-0790

Collar

3

KD1-35923-0160

Collar

4

KD0-09201-0980

Bearing, Ball

5

KD0-35200-0460

Stator Assembly

6

KD0-35300-0350

Bracket Assembly

7

KD0-09201-1140

Bearing

8

KD0-35926-0070

Retainer

9

KD0-35951-0060

Packing

10

KD0-35926-0090

Retainer

11

KD1-33926-0730

Retainer

12

KD0-0275-06802

Bolt

13

KD0-35411-0640

Pulley

14

KD0-35421-0240

Fan

15

KD1-0330-16012

Washer

16

KD1-0335-16002

Washer, Spring

17

KD0-0280-16022

Nut

18

KD0-35120-0290

Coil, Field

|19

KD0-35700-0950

Bracket Assembly

19

KD0-35710-1150

Bracket

20

KD0-35730-0700

Rectifier Assembly

21

KD0-09170-2501

Condenser

22

KD0-35943-0150

Bushing, Insulate

23

KD0-35923-0130

Collar

24

KD0-35943-0160

Bushing

25

KD0-35943-0140

Bushing

26

KD0-35943-0170

Bushing

27

KD0-35784-0210

Bar

28

KD0-35784-0290

Bar

29

KD0-09057-0220

Washer

30

KD7-35719-0211

Regulator Assembly

31

KD0-35761-0250

Cover
