Запчасти Komatsu PC350LC-8 T-A СТРЕЛА ЦИЛИНДР СТРЕЛЫ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-01-0A431

BOOM CYLINDER ASSEMBLY

1

707-13-14580

CYLINDER

2

707-76-90490

BUSHING

3

07145-00090

SEAL, DUST

4

07020-00000

FITTING, GREASE

5

07043-00108

PLUG

6

707-58-10720

ROD

7

707-76-10290

BUSHING

8

07145-00100

SEAL, DUST

9

707-71-34800

COLLAR

10

707-35-91420

RING, BACK-UP

11

07000-15130

O-RING

12

707-71-61090

PLUNGER

13

707-27-14890

HEAD

14

176-63-56170

SEAL, DUST

15

07179-13114

RING, SNAP

16

707-52-90780

BUSHING

17

707-51-10030

PACKING, ROD

18

707-51-10640

RING, BUFFER

19

707-35-91420

RING, BACK-UP

20

07000-15130

O-RING

21

01010-81875

BOLT

22

707-41-11840

WASHER

23

707-36-14650

PISTON

24

01310-01216

SCREW

25

707-44-14180

RING, PISTON

26

707-39-14110

RING, WEAR

27

707-44-14910

RING

28

07001-05090

RING, BACK-UP

29

07000-15090

O-RING

30

707-86-11580

TUBE, L.H.

|$31

707-86-11590

TUBE, R.H.

31

207-63-54580

TUBE, L.H.

|$33

207-63-54680

TUBE, R.H.

32

07372-21060

BOLT

33

01643-51032

WASHER

34

07000-13035

O-RING

35

207-63-54590

BRACKET

36

707-88-21370

BAND

37

07372-21240

BOLT

38

01643-51232

WASHER

39

07283-33442

U-BOLT

40

01643-31032

WASHER

41

01597-01009

NUT

42

01010-81025

BOLT

43

01643-31032

WASHER

44

707-88-33040

CAP

45

07371-31049

FLANGE, SPLIT

46

07372-21035

BOLT

47

01643-51032

WASHER

|$50

707-99-58080

SERVICE KIT
