Запчасти Komatsu PC350LC-8 P-A МОТОР ХОДА (/) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

1

708-8H-32120

SHAFT

2

708-8H-32150

BEARING

3

708-8H-32170

BEARING

4

708-8H-05050

SPACER KIT

|$5

NSS

SPACER, 1.6 MM

|$6

NSS

SPACER, 1.7 MM

|$7

NSS

SPACER, 1.8 MM

|$8

NSS

SPACER, 1.9 MM

|$9

NSS

SPACER, 2.0 MM

|$10

NSS

SPACER, 2.1 MM

|$11

NSS

SPACER, 2.2 MM

5

708-1F-12281

SEAL, OIL

6

708-8H-32160

SPACER

7

04065-07825

RING, SNAP

|$15

708-8H-04810

CYLINDER BLOCK ASSEMBLY

8

708-8H-33710

BLOCK, CYLINDER

9

708-8H-33810

PLATE, VALVE

10

708-18-13230

PIN

11

708-8H-33360

PIN

12

708-8H-33141

SPACER

13

708-8H-33750

SPRING

14

04065-06020

RING, SNAP

15

708-8H-33512

RETAINER

16

708-8H-33340

RETAINER, SHOE

17

708-8H-33650

PISTON SUB ASSEMBLY

18

708-8H-33471

CAM, ROCKER

19

04260-02857

BALL

20

708-8H-34190

PISTON

21

708-8H-34151

SPRING

22

708-8K-14210

PLUG

23

07002-13334

O-RING

24

708-8H-35130

PLATE

25

708-8H-35180

DISC

26

708-8H-35141

PISTON, BRAKE

27

07000-15175

O-RING

28

07001-05175

RING, BACK-UP

29

07000-15195

O-RING

30

07001-05195

RING, BACK-UP

31

708-8H-35150

SPRING
