Запчасти Komatsu PC350LC-8 N-A МОТОР ПОВОРОТА (/) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

706-7K-41610

SHAFT

2

706-77-43890

BEARING

2

706-77-43880

BEARING

3

706-7K-41810

SPACER

4

706-77-42051

SPRING

5

706-77-42041

SEAT

6

706-77-42890

BEARING

7

706-77-05010

SPACER KIT

|$10

NSS

SPACER, 2.3 MM

|$11

NSS

SPACER, 2.5 MM

|$12

NSS

SPACER, 2.7 MM

8

04064-06525

RING, SNAP

9

706-8J-41420

SEAL, OIL

9

706-7K-41650

SEAL, OIL

10

706-7K-41920

SPACER

11

04065-07525

RING

12

706-7K-41210

BLOCK, CYLINDER

13

706-7K-41710

PLATE, VALVE

14

708-18-13230

PIN

15

706-7K-41120

SHAFT, CENTER

16

706-77-42130

RING, CENTER

17

706-7K-41140

SPRING

|$24

706-7K-05010

RETAINER KIT

18

NSS

RETAINER

19

NSS

SCREW

20

706-7K-41160

PISTON SUBASSEMBLY

21

706-7K-91340

PLATE

22

706-7K-91350

DISC

23

706-7K-91111

PISTON, BRAKE

24

07000-B5230

O-RING

24

07000-15230

O-RING

25

708-8H-15220

O-RING

25

706-86-90290

O-RING

26

706-7K-91360

SPRING
