Запчасти Komatsu PC350LC-8 K-A КАБИНА ПЕРЕДН. ОКНА АНТИВАНДАЛЬН. OPERATOR\XD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$1

20Y-53-00031

WINDOW ASSEMBLY

1

20Y-53-11511

FRAME

2

20Y-53-11520

GLASS

3

20Y-54-51531

SEAL

4

20Y-53-11551

SEAL

5

22B-54-15411

LOCK ASSEMBLY

6

22B-54-15440

CASE

7

22B-54-15470

KNOB

8

22B-54-15421

LOCK ASSEMBLY

9

22B-54-15450

CASE

10

22B-54-15480

KNOB

11

01010-D0816

BOLT

12

418-54-35450

WASHER

13

20Y-54-52621

ROLLER

14

20Y-54-52681

ROLLER

15

20Y-53-12330

PIN

16

20Y-54-14590

HANDLE

17

01245-00616

SCREW, SOCKET HEAD

18

01643-70623

WASHER

19

20Y-53-12830

BRACKET

20

01245-00816

SCREW, SOCKET HEAD

21

01643-70823

WASHER

22

20Y-54-51670

STOPPER

23

20Y-54-51680

STOPPER

24

01252-80616

BOLT, SOCKET HEAD

25

01643-70623

WASHER

26

20Y-53-11561

BLOCK ASSEMBLY

27

01245-00816

SCREW, SOCKET HEAD

28

01643-70823

WASHER

29

20Y-53-11661

BRACKET

30

01245-00816

SCREW, SOCKET HEAD

31

01643-70823

WASHER

32

21J-06-12440

SWITCH

33

01583-11811

NUT

34

20Y-53-11581

BRACKET

35

20Y-53-11641

BRACKET

36

01435-00612

BOLT

37

20Y-54-11611

STOPPER

38

01580-11008

NUT

39

20Y-54-51621

STRIKER

40

01584-31008

NUT, FLANGED

41

01643-71032

WASHER

42

20Y-53-11540

SEAL

43

20Y-54-51420

SEAL

44

20Y-53-12531

COVER

45

20Y-53-12310

COLLAR

46

01245-00616

SCREW, SOCKET HEAD

47

01643-70623

WASHER
