Запчасти Komatsu PC350LC-8 A-AA БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC350LC-8 - A-AA БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ
2
8
18
26
23
17
16
16
8
9
12
25
17
11
15
5
6
15
13
3
4
7
24
19
22
16
1
21
14
10
20

Артикул

Название

Примечание

Количество

|$0

6745-22-1180

BLOCK KIT, CYLINDER

1

6216-94-3450

DRAINCOCK (1/4 NPTF)

2

6745-21-1120

PLUG, THREADED

|$3

6735-21-1910

PLUG, THREADED (M14-1.50)

3

6735-21-1930

SEAL, O-RING

4

NSS

PLUG, THREADED

|$6

6732-21-1960

PLUG, THREADED (M10-1.00x9.5)

5

NSS

PLUG, THREADED

6

6735-21-1970

SEAL, O-RING

7

6732-21-6120

DOWEL, PIN

8

6742-01-1470

DOWEL, PIN

9

6742-01-1480

PLUG, EXPANSION

10

6736-11-4460

BOLT (M8-1.25x55)

11

6742-01-4080

SEAL, O-RING

12

6745-21-1910

BOLT

13

6745-11-1910

PIPE, PLUG

14

6745-21-1611

NOZZLE, PISTON COOLING

|$17

NSS

BLOCK, CYLINDER

15

6742-01-1360

PLUG, EXPANSION

16

6742-01-1370

PLUG, EXPANSION

17

6732-21-1810

PLUG, EXPANSION

18

6742-01-1420

PLUG, EXPANSION

19

6742-01-5160

BUSHING

20

6741-21-1140

BOLT (M14-2.00x135)

21

6741-21-1130

CAP, MAIN BEARING

22

6745-41-2151

GUIDE, TAPPET

23

NSS

BLOCK, CYLINDER

24

6754-21-1910

BOLT

|$28

6742-01-5159

KIT, LINER

25

NSS

LINER, CYLINDER

26

6742-01-1520

SEAL, RECTANGULAR

Выбрано товаров: 31
