Запчасти Komatsu PC350LC-8 H8-A MULTI PATTERN КЛАПАН ( WAY) И СОЕДИН-ЕS (заводской номер A- ) С ТРУБЫ ГИДРАВЛИКА

1

20Y-62-A1540

HANDLE

2

207-62-A3620

BRACKET

3

20Y-62-A1531

VALVE, MULTI PATTERN

4

207-62-A3610

BRACKET

5

208-62-71870

BRACKET

6

203-62-59270

BOLT, WING

7

01640-20816

WASHER

8

04050-12015

PIN, COTTER

9

01010-80620

BOLT

10

01643-30623

WASHER

11

01010-80880

BOLT

12

01643-30823

WASHER

13

01010-81025

BOLT

14

01643-31032

WASHER

15

207-62-25720

ELBOW, 45 DEGREE

16

04002-11423

O-RING

17

21W-62-42490

ELBOW, 90 DEGREE

18

20Y-62-22160

ADAPTER

19

07002-11423

O-RING

20

02896-11009

O-RING

21

11Y-62-12510

ELBOW, 90 DEGREE

22

07002-11423

O-RING

23

20Y-62-25720

ELBOW, 45 DEGREE

24

07002-11423

O-RING

25

207-62-25720

ELBOW, 45 DEGREE

26

07002-11423

O-RING

27

11Y-62-12240

ELBOW, 45 DEGREE

28

07002-11423

O-RING

29

01011-81200

BOLT

30

01643-31232

WASHER

31

208-62-A1930

HOSE, L=1680 MM, GREEN BAND, D2 PORT

32

208-62-A1950

HOSE, L=1780 MM, BROWN BAND, B2 PORT

33

208-62-72280

HOSE, L=1350 MM, BLUE BAND, C1 PORT

34

208-62-72230

HOSE, L=700 MM,YELLOW BAND, A1 PORT

35

208-62-A1940

HOSE, L=1800 MM, BLUE BAND, C2 PORT

36

208-62-A1960

HOSE, L=1615 MM,YELLOW BAND, A2 PORT

37

208-62-72210

HOSE, L=400 MM,GREEN BAND, D1 PORT

38

208-62-72260

HOSE, L=1350 MM,BROWN BAND, B1 PORT

39

01010-81225

BOLT

40

20Y-62-15951

CLIP

41

04434-53212

CLIP

42

01010-81225

BOLT

43

01643-31232

WASHER

44

01643-31232

WASHER

45

07002-11423

O-RING

N/I

20Y-62-22850

BAND, GREEN

N/I

20Y-62-22810

BAND, YELLOW

N/I

20Y-62-22860

BAND, BROWN

N/I

20Y-62-22820

BAND, BLUE

N/I

20Y-00-A2150

DECAL
