Запчасти Komatsu PC350LC-8 РУКОЯТЬ, ЦИЛИНДР КОВША (№-8) РУКОЯТЬ, MM, УСИЛЕНН., -ДОПОЛН. АКТУАТОР ТРУБЫ, АККУМУЛЯТОР

|$0

707-01-0H770

Cylinder Assembly

1

707-13-14591

Cylinder

2

707-76-90490

Bushing

3

07145-00090

Seal, Dust, (Kit : K16)

4

07020-00000

Fitting, Grease

5

707-58-10730

Rod, Piston

6

207-63-76170

Bushing

7

207-70-72120

Seal, Dust, (Kit : K16)

8

07020-00000

Fitting, Grease

9

707-27-14931

Head

10

707-56-10740

Seal, Dust, (Kit : K16)

11

07179-13114

Ring, Snap

12

707-52-90781

Bushing

13

707-51-10030

Packing, Rod, (Kit : K16)

14

707-51-10640

Ring, Buffer, (Kit : K16)

15

707-35-91420

Ring, Back-up, (Kit : K16)

16

07000-15130

O-ring, (Kit : K16)

17

01010-81875

Bolt

18

707-41-11840

Washer

19

707-36-14650

Piston

20

01310-01216

Screw

21

707-44-14180

Ring, Piston, (Kit : K16)

22

707-39-14110

Ring, Wear, (Kit : K16)

23

707-44-14910

Ring

24

07001-05090

Ring, Back-up, (Kit : K16)

25

07000-15090

O-ring, (Kit : K16)

26

707-86-11621

Tube

27

207-63-73180

Tube

28

07372-21060

Bolt

29

01643-51032

Washer

30

07000-13035

O-ring, (Kit : K16)

31

207-63-73790

Bracket

32

707-88-21410

Band

33

07372-21240

Bolt

34

01643-51232

Washer

35

707-88-10150

Clamp

36

01010-81245

Bolt

37

01643-31232

Washer

38

707-88-33040

Cap

39

07371-31049

Flange, Split

40

07372-21035

Bolt

41

01643-51032

Washer
