Запчасти Komatsu PC350LC-8 КЛАПАН PPC(ДЛЯ ХОДА) (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

702-16-04250

PILOT VALVE

1

BODY,VALVE

2

VALVE

3

702-16-51140

SHIM, 0.30MM

4

702-16-53420

SPRING

5

702-16-53140

RETAINER

6

702-16-54420

SPRING

7

702-16-53170

PISTON

8

702-16-71150

SEAL

9

702-16-71160

SEAT

10

702-16-73630

CASE

11

LEVER

12

SHAFT

13

PLATE

14

01010-80855

BOLT

15

01643-30823

WASHER

16

01010-80816

BOLT

17

702-16-54331

WASHER, 1.60MM

17

702-16-54341

WASHER, 1.30MM

17

702-16-54351

WASHER, 1.00MM

17

702-16-56380

WASHER, 1.90MM

17

702-16-56390

WASHER, 2.20MM

18

04025-00432

PIN,SPRING

19

702-16-54430

BUSHING

20

07000-12018

O-RING

21

702-16-73610

DAMPER ASS'Y

22

01023-10306

SCREW

23

702-16-73650

PIN

24

04022-04016

PIN,DOWEL
