Запчасти Komatsu PC350LC-8 ОСНОВН. НАСОС (7/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-2G-00700

PUMP ASS'Y

|$3

708-2G-01070

PUMP SUB ASS'Y

1

708-2G-12190

SHAFT

2

708-2G-12251

BEARING

3

708-2G-05010

WASHER KIT

3

WASHER, 3.0MM

3

WASHER, 3.1MM

3

WASHER, 3.2MM

4

708-1F-12270

RING,SNAP

|$11

708-2G-04270

BLOCK ASS'Y,REAR

5

BLOCK,CYLINDER

6

PLATE,VALVE

7

708-18-13230

PIN

8

04065-05520

RING

9

708-2G-13131

SEAT

10

708-2G-13152

SPRING

11

708-2G-13141

SEAT

12

708-2G-13510

GUIDE,RETAINER

13

708-2H-23360

PIN

14

708-2G-13341

RETAINER,SHOE

15

708-2G-13370

PISTON SUB ASS'Y

|$23

708-2G-04290

CRADLE SUB ASS'Y

16

CRADLE

17

CAM,ROCKER

18

04020-01434

PIN,DOWEL

19

07000-B1009

O-RING

20

01252-61230

BOLT
