Запчасти Komatsu PC350LC-7-BA ОСНОВН. КОНСТРУКЦИЯ (КОНСОЛЬ) (ПРАВ.) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

22U-43-23110

STAY

2

207-06-71170

WIRING HARNESS

3

22U-43-23120

BRACKET

4

22U-43-23130

STAY

5

207-06-71180

SWITCH

6

22U-43-23140

COVER

7

22U-06-22420

POTENTIOMETER ASS'Y

8

22U-06-22470

KNOB

9

22B-06-11910

SWITCH

10

22U-06-22480

PLATE

11

22U-06-22190

SWITCH

12

22U-06-22290

SWITCH

13

22U-06-22390

SWITCH

14

20Y-06-23770

CLIP

15

20Y-06-23920

CLAMP

16

08034-10414

BAND

17

01023-60410

SCREW

18

01023-60512

SCREW

19

01023-10508

SCREW

20

01023-10512

SCREW

21

01601-20513

WASHER

22

01023-60620

SCREW

23

01023-70514

SCREW

24

22U-43-23210

COVER

|25

22U-06-22370

SWITCH ASS'Y

25

22U-06-22340

WIRING HARNESS

26

PLATE

27

208-43-71420

CAP

28

22U-43-23220

TRIM

29

22U-43-23230

COVER

30

22U-43-23240

FRAME

31

22U-43-23250

SHEET

32

22U-43-23260

CLIP

33

22U-43-23270

GROMMET

34

01370-00512

SCREW

35

01023-60616

SCREW

36

569-06-61960

RELAY

37

01435-00612

BOLT

38

01023-60410

SCREW

39

22U-43-23711

COVER

40

01023-10614

SCREW

41

01643-30623

WASHER

42

01010-81030

BOLT

43

01643-31032

WASHER
