Запчасти Komatsu PC350LC-6Z ОСНОВН. КЛАПАН (-АКТУАТОР) (8/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC350LC-6Z - ОСНОВН. КЛАПАН (-АКТУАТОР) (8/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58

Артикул

Название

Примечание

Количество

|1

723-48-16501

CONTROL VALVE

|1

723-48-16500

CONTROL VALVE

|1

723-48-16102

CONTROL VALVE

|1

723-48-16101

CONTROL VALVE

|1

709-70-74302

VALVE ASS'Y,SUCTION AND SAFETY

1

SLEEVE

2

SLEEVE

3

POPPET

4

PISTON

5

PLUG

6

POPPET

7

SCREW

8

SPRING

9

SPRING

10

SPRING

11

SEAL

12

SEAL

13

709-25-11390

O-RING

14

O-RING

15

O-RING

16

NUT

|17

723-40-90101

VALVE ASS'Y,SUCTION AND SAFETY

|17

723-40-90100

VALVE ASS'Y,SUCTION AND SAFETY

17

SLEEVE

18

SLEEVE

19

POPPET

20

PISTON

|20

PISTON

21

SLEEVE

22

POPPET

23

UNION

24

PISTON

25

SPRING

26

SPRING

27

SPRING

28

SEAL

29

SEAL

30

709-25-11390

O-RING

31

O-RING

|31

O-RING

32

NUT

33

NUT

34

HOLDER

35

O-RING

|35

O-RING

36

SPRING

37

SEAL

|38

723-40-85100

VALVE ASS'Y,SUCTION

38

SLEEVE

39

VALVE

40

SPRING

41

SEAL

42

709-25-11390

O-RING

|43

709-70-74203

VALVE ASS'Y

43

SLEEVE

44

SLEEVE

45

POPPET

46

PISTON

47

PLUG

48

POPPET

49

SCREW

50

SPRING

51

SPRING

52

SPRING

53

SEAL

54

SEAL

55

709-25-11390

O-RING

56

O-RING

57

O-RING

58

NUT

Выбрано товаров: 70
