Запчасти Komatsu PC350HD-8 A9-AA ГЕНЕРАТОР A ДВИГАТЕЛЬ

|$0

600-861-6110

ALTERNATOR

1

KD0-35100-0300

ROTOR ASSEMBLY

2

KD1-33923-0790

COLLAR

3

KD1-35923-0160

COLLAR

4

KD0-09201-0980

BEARING, BALL

5

KD0-35200-0460

STATOR ASSEMBLY

6

KD0-35300-0350

FRONT BRACKET ASSEMBLY

7

KD0-09201-1140

BEARING, BALL

8

KD0-35926-0070

RETAINER

9

KD0-35951-0060

PACKING

10

KD0-35926-0090

RETAINER

11

KD1-33926-0730

RETAINER

12

KD0-0275-06802

BOLT

13

KD0-35411-0640

PULLEY

14

KD0-35421-0240

FAN

15

KD1-0330-16012

WASHER, PLAIN

16

KD1-0335-16002

WASHER, SPRING

17

KD0-0280-16022

NUT

18

KD0-35120-0290

FIELD COIL

|$19

KD0-35700-0950

REAR BRACKET ASSEMBLY

19

KD0-35710-1150

BRACKET, REAR

20

KD0-35730-0700

RECTIFIER ASSEMBLY

21

KD0-09170-2501

CONDENSER

22

KD0-35943-0150

BUSH, INSULATE

23

KD0-35923-0130

COLLAR

24

KD0-35943-0160

BUSH, INSULATE

25

KD0-35943-0140

BUSH, INSULATE

26

KD0-35943-0170

BUSH, INSULATE

27

KD0-35784-0210

BAR, CONNECT

28

KD0-35784-0290

TERMINAL, PLATE

29

KD0-09057-0220

WASHER

30

KD7-35719-0211

REGULATOR ASSEMBLY

31

KD0-35761-0250

COVER
