Запчасти Komatsu PC350-8M0 РУКОЯТЬ, ЦИЛИНДР КОВША (№8-) РУКОЯТЬ, MM, УСИЛЕНН., -НАВЕСН. ОБОРУД

|$0

707-E1-00710

Cylinder Assembly

1

721-13-14060

Cylinder

2

721-58-10410

Rod, Piston

3

707-76-90490

Bushing

4

07145-00090

Seal, Dust, (Kit : K12)

5

07020-00000

Fitting, Grease

6

207-63-76170

Bushing

7

207-70-72120

Seal, Dust, (Kit : K12)

8

07020-00000

Fitting, Grease

9

707-27-14690

Head, Cylinder

10

707-56-10740

Seal, Dust, (Kit : K12)

11

07179-13114

Ring, Snap

12

707-51-10860

Packing, Rod, (Kit : K12)

13

707-51-10650

Ring, Buffer, (Kit : K12)

14

707-52-90781

Bushing

15

07000-B5130

O-ring, (Kit : K12)

16

707-35-31310

Ring, Back-up, (Kit : K12)

17

01010-81875

Bolt

18

707-41-11840

Washer

19

707-75-10160

Ring, Snap

20

707-36-14650

Piston

21

707-44-14150

Ring, Piston, (Kit : K12)

22

707-39-14110

Ring, Wear, (Kit : K12)

23

707-44-14910

Ring

24

07000-B5090

O-ring, (Kit : K12)

25

707-35-30900

Ring, Back-up, (Kit : K12)

26

01310-01216

Screw

27

707-86-16330

Tube

28

207-63-73181

Tube

29

07372-21060

Bolt

30

01643-51032

Washer

31

07000-13035

O-ring, (Kit : K12)

32

707-88-51380

Bracket

33

707-88-21410

Band

34

07372-21240

Bolt

35

01643-51232

Washer

36

707-88-10150

Clamp

37

01010-81245

Bolt

38

01643-31232

Washer

39

07371-31049

Flange, Split

40

707-88-33040

Cap

41

07372-21035

Bolt

42

01643-51032

Washer
