Запчасти Komatsu PC350-8 ЦИЛИНДР СТРЕЛЫ, ПРАВ. (№9-) ЦИЛИНДР СТРЕЛЫ, ЧАС. СИСТ. СМАЗКИ ТИП, С LIMETED STROKE

|$0

707-01-0E231

Cylinder Assembly

1

707-13-14581

Cylinder

2

707-58-10720

Rod

3

707-76-90490

Bushing

4

07145-00090

Seal, Dust

5

07020-00000

Fitting, Grease

6

07043-00108

Plug, Taper

7

707-76-10290

Bushing

8

07145-00100

Seal, Dust

9

707-71-34800

Collar

10

707-35-91420

Ring, Back-up

11

07000-15130

O-ring

12

707-71-61090

Plunger

13

707-27-14890

Head

14

707-56-10740

Seal, Dust

15

07179-13114

Ring, Snap

16

707-51-10030

Packing, Rod

17

707-51-10640

Ring, Buffer

18

707-52-90780

Bushing

19

07000-15130

O-ring

20

707-35-91420

Ring, Back-up

21

01010-81875

Bolt

22

707-41-11840

Washer

23

707-75-10160

Ring, Snap

24

707-36-14650

Piston

25

707-44-14180

Ring, Piston

26

707-39-14110

Ring, Wear

27

707-44-14910

Ring

28

07000-15090

O-ring

29

07001-05090

Ring, Back-up

30

01310-01216

Screw

31

707-81-14030

Spacer

32

707-86-11590

Tube

33

707-86-00870

Tube

34

707-87-14700

Plug

35

07002-63034

O-ring

36

207-63-54590

Bracket

37

07372-21060

Bolt

38

01643-51032

Washer

39

07000-13035

O-ring

40

707-88-21370

Band

41

07372-21240

Bolt

42

01643-51232

Washer

43

07283-33442

Clip, Pipe

44

01597-01009

Nut

45

01643-31032

Washer

46

01010-81025

Bolt

47

01643-31032

Washer

48

07371-31049

Flange, Split

49

707-88-33040

Cap

50

07372-21035

Bolt

51

01643-51032

Washer
