Запчасти Komatsu PC350-8 ЦИЛИНДР СТРЕЛЫ, ЛЕВ. (№-8) ЦИЛИНДР СТРЕЛЫ, ЧАС. СИСТ. СМАЗКИ ТИП

|$0

707-01-0A430

Cylinder Assembly

1

707-13-14580

Cylinder

2

707-58-10720

Rod

3

707-76-90490

Bushing

4

07145-00090

Seal, Dust, (Kit : K03)

5

07020-00000

Fitting, Grease

6

07043-00108

Plug, Taper

7

707-76-10290

Bushing

8

07145-00100

Seal, Dust, (Kit : K03)

9

707-71-34800

Collar

10

707-35-91420

Ring, Back-up, (Kit : K03)

11

07000-15130

O-ring, (Kit : K03)

12

707-71-61090

Plunger

13

707-27-14930

Head, Cylinder

14

707-56-10740

Seal, Dust, (Kit : K03)

15

07179-13114

Ring, Snap

16

707-51-10030

Packing, Rod, (Kit : K03)

17

707-51-10640

Ring, Buffer, (Kit : K03)

18

707-52-90780

Bushing

19

07000-15130

O-ring, (Kit : K03)

20

707-35-91420

Ring, Back-up, (Kit : K03)

21

01010-81875

Bolt

22

707-41-11840

Washer

23

707-36-14650

Piston

24

707-44-14180

Ring, Piston, (Kit : K03)

25

707-39-14110

Ring, Wear, (Kit : K03)

26

707-44-14910

Ring

27

07000-15090

O-ring, (Kit : K03)

28

07001-05090

Ring, Back-up, (Kit : K03)

29

01310-01216

Screw

30

707-86-11580

Tube

31

207-63-54580

Tube

32

207-63-54590

Bracket

33

01435-01055

Bolt

34

07000-13035

O-ring, (Kit : K03)

35

707-88-21370

Band

36

01435-01235

Bolt

37

07283-23442

Clip

38

01599-01011

Nut

39

01643-31032

Washer

40

01435-01025

Bolt

41

07371-31049

Flange, Split

42

707-88-33040

Cap

43

07372-21035

Bolt

44

01643-51032

Washer
