Запчасти Komatsu PC350-8 МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА, (/) (№-9) МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА, БЕЗ ХОЛОДН. СПЕЦ-ЯIFICATION КАТКИ

|$0

207-27-00441

Final Drive Assembly

|$1

207-27-00440

Final Drive Assembly

|$2

708-8H-00320

Motor Assembly

1

708-8H-32120

Shaft

2

708-8H-32150

Bearing

3

708-8H-32170

Bearing

4

708-8H-05050

Spacer Kit

4

Spacer, T=1.6mm

4

Spacer, T=1.7mm

4

Spacer, T=1.8mm

4

Spacer, T=1.9mm

4

Spacer, T=2.0mm

4

Spacer, T=2.1mm

4

Spacer, T=2.2mm

5

708-1F-12281

Seal, Oil

6

708-8H-32160

Spacer

7

04065-07825

Ring, Snap

|$17

708-8H-04810

Cylinder Block Assembly

8

708-8H-33710

Block, Cylinder

9

708-8H-33810

Plate, Valve

10

708-18-13230

Pin

11

708-8H-33360

Pin

12

708-8H-33141

Spacer

13

708-8H-33750

Spring

14

04065-06020

Ring, Snap

15

708-8H-33512

Guide, Retainer

16

708-8H-33340

Retainer, Shoe

17

708-8H-33650

Piston Subassembly

18

708-8H-33471

Cam, Rocker

19

04260-02857

Ball, Retainer

20

708-8H-34190

Piston

21

708-8H-34151

Spring

22

X17-8320160

Plug

23

07002-13334

O-ring

24

708-8H-35130

Plate

25

708-8H-35180

Disc

26

708-8H-35141

Piston, Brake, Brake

27

07000-15175

O-ring

28

07001-05175

Ring, Back-up

29

07000-15195

O-ring

30

07001-05195

Ring, Back-up

31

708-8H-35150

Spring
