Запчасти Komatsu PC340NLC-7K-E0 ОСНОВН. КОНСТРУКЦИЯ (КАБИНА) (КОНСОЛЬ¤ ПРАВ.) (МАСТЕР КЛЮЧ) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

22U-43-23111

PLATE

2

207-06-75170

WIRING HARNESS

3

22U-43-23120

BRACKET

4

22U-43-23130

STAY

5

207-06-71180

SWITCH

6

208-43-71690

COVER

7

22U-06-22420

POTENTIOMETER ASS'Y

|7

22U-06-22380

POTENTIOMETER

|7

22U-06-22450

BRACKET

|7

22U-06-22460

SPRING

8

22U-06-22470

KNOB

9

08086-20000

SWITCH

10

22U-06-22480

PLATE

11

22U-06-22320

COVER

12

22U-06-22290

SWITCH

13

22U-06-22390

SWITCH

14

20Y-06-23770

CLIP

15

20Y-06-23920

CLAMP

16

08034-10414

BAND

17

01023-60408

SCREW

18

01023-60512

SCREW

19

01023-10508

SCREW

20

01023-10512

SCREW

21

01601-20513

WASHER,SPRING

22

01023-60630

SCREW

23

01640-20610

WASHER

24

208-43-71610

CUSHION

25

208-43-71620

PIPE

26

01023-70514

SCREW

27

22U-43-23210

COVER

|28

20Y-06-31320

SWITCH ASS'Y

28

20Y-06-31330

WIRING HARNESS

29

PLATE

30

208-43-71420

CAP

31

22U-43-23230

COVER

32

208-43-71670

FRAME

33

22U-43-23250

SHEET

34

22U-43-23260

CLIP

35

01023-60616

SCREW

36

569-06-61960

RELAY

37

01435-00612

BOLT

38

01023-60410

SCREW

39

22U-43-23711

COVER

40

01023-10614

SCREW

41

01643-30623

WASHER

42

01010-81030

BOLT

43

01643-31032

WASHER
