Запчасти Komatsu PC340NLC-6K МОТОР ПОВОРОТА (/) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|1

706-77-01170

MOTOR ASS'Y

1

706-77-43210

CASE,MOTOR

2

706-77-43180

BOLT

3

706-7E-11440

O-RING

4

706-77-40010

BEARING

5

706-77-43840

PLATE,VALVE

6

708-18-13230

PIN

7

706-77-43080

SHAFT,CENTER

8

706-77-43191

BLOCK

9

706-77-42110

SPRING

10

706-77-42130

RING,CENTER

11

706-77-42160

PISTON SUB ASS'Y

12

706-77-42041

SEAT

13

706-77-42051

SPRING

14

706-77-43260

RETAINER

15

706-75-41271

SCREW

16

706-77-43860

SHAFT

17

706-77-43880

BEARING

18

706-77-42890

BEARING

|19

706-77-05010

SPACER KIT

19

SPACER¤ 2.3MM

20

SPACER¤ 2.5MM

21

SPACER¤ 2.7MM

22

04064-06525

RING,SNAP

23

706-77-43060

COVER

24

07000-02125

O-RING

25

706-77-43950

SEAL,OIL

26

04071-00130

RING,SNAP

27

706-77-91540

PLATE

28

706-77-91550

DISC

29

706-77-91580

PISTON,BRAKE

30

07000-15180

O-RING

31

708-8H-15220

O-RING

32

706-75-42830

PIN,DOWEL

33

706-77-91510

SPRING
