Запчасти Komatsu PC340NLC-6K ПРАВ. ДВЕРЬ (КАБИНА) ЧАСТИ КОРПУСА

1

207-54-K2311

COVER

|1

207-54-K2310

COVER

2

20Y-54-K7450

HINGE

3

198-54-41982

LOCK ASS'Y

4

207-54-K2630

COVER

|4

20Y-54-K7413

COVER

5

20Y-54-K7450

HINGE

6

198-54-41982

LOCK ASS'Y

7

205-54-53550

DOVE TAIL

8

01010-80612

BOLT

9

01643-30623

WASHER

10

207-54-K3120

FRAME

|10

207-54-K2290

FRAME

11

20Y-54-33170

BRACKET

12

01010-81230

BOLT

13

01643-31232

WASHER

14

205-54-51970

DOVE TAIL

15

01010-80616

BOLT

16

01643-30623

WASHER

17

20Y-54-K7421

PLATE

18

01010-81230

BOLT

19

01643-31232

WASHER

20

20E-54-K2230

BAR

21

20Y-54-K7441

SEAL

22

207-54-K2490

SEAL

23

20Y-54-11611

STOPPER

24

01580-11008

NUT

25

207-54-K2340

PLATE

26

01010-81225

BOLT

27

01643-51232

WASHER

28

20E-54-K2230

BAR

29

20Y-54-K7430

SEAL

30

207-54-K2350

SEAL

31

207-54-11611

STOPPER

32

01580-11008

NUT

33

01010-81235

BOLT

|33

01010-81235

BOLT

34

01643-31232

WASHER

|34

01643-31232

WASHER

35

20Y-54-33290

PLATE

36

207-54-K2321

COVER

37

207-54-K2540

SHEET

38

01010-81230

BOLT

39

01643-31232

WASHER

40

01010-81230

BOLT

41

01643-31232

WASHER

42

20Y-54-K7741

SHEET

43

207-54-K2380

SHEET

44

207-04-K1280

BRACKET

45

01010-81240

BOLT

46

01643-31232

WASHER
