Запчасти Komatsu PC340NLC-6 КАБИНА (ПЕРЕДН. ОКНА) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

20Y-54-00492

OPERATOR'S CAB ASS'Y

|1

20Y-54-00491

OPERATOR'S CAB ASS'Y

|1

20Y-54-43104

FRONT WINDOW A

|1

20Y-54-43103

WINDOW ASS'Y

1

20Y-54-43112

WINDOW

2

20Y-54-38122

GLASS

3

20Y-54-38133

WEATHER STRIP

|3

20Y-54-38132

WEATHER STRIP

4

20Y-54-38143

SEAL

5

20Y-54-38152

SEAL

6

20Y-54-43130

LATCH ASS'Y

7

20Y-54-43140

LATCH ASS'Y

8

01435-40816

BOLT

|8

01435-30816

BOLT

9

20Y-54-14290

STOPPER

10

01580-11008

NUT

11

20Y-54-14590

HANDLE

12

01023-10616

SCREW

13

20Y-54-14310

STRIKER

14

20Y-54-14280

SCREW

15

20Y-54-37810

STOPPER

16

01023-70416

SCREW

17

20Y-54-37820

STOPPER

18

01023-70416

SCREW

19

20Y-54-36835

BLOCK

20

20Y-54-36845

BLOCK

21

01252-50635

BOLT

22

01641-50608

WASHER

23

20Y-54-39152

ROLLER

24

205-54-63310

LOCK ASS'Y

25

01435-40820

BOLT

|25

01435-30820

BOLT

26

20Y-54-39363

BRACKET

27

01435-40820

BOLT

|27

01435-30820

BOLT

28

154-61-16570

WASHER

29

08074-40000

SWITCH

30

01583-11811

NUT

31

20Y-54-39590

WIRING HARNESS

32

20Y-54-36150

GROMMET

33

08051-00801

CLIP

34

20Y-54-14721

LOCK

35

01435-40820

BOLT

|35

01435-30820

BOLT

|36

20Y-54-43201

LOWER WINDOW ASS'Y

36

20Y-54-43210

LATCH ASS'Y

37

20Y-54-43220

LATCH ASS'Y

38

20Y-54-36142

PLATE

39

08037-01610

GROMMET

40

01225-70612

SCREW

41

20Y-54-36211

COVER

42

20Y-54-36113

GLASS

43

20Y-54-36171

SEAT

44

20Y-54-36230

SHIM¤ 2.0MM

45

01370-00620

SCREW

46

01643-30623

WASHER

47

20Y-54-36182

STOPPER

48

01435-40820

BOLT

|48

01435-30820

BOLT
