Запчасти Komatsu PC340NLC-6 ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

207-63-X9031

ARM CYLINDER GROUP

G-1

207-63-X2521

ARM CYLINDER GROUP

|1

207-63-02522

ARM CYLINDER ASS'Y

|1

207-63-02521

ARM CYLINDER ASS'Y

1

207-63-63741

CYLINDER

2

707-76-10130

BUSHING

3

07145-00100

SEAL,DUST (KIT)

4

207-63-63722

ROD

|4

207-63-63721

ROD

5

707-76-10130

BUSHING

6

07145-00100

SEAL,DUST (KIT)

7

707-71-32800

COLLAR

8

707-35-91640

RING,BACK-UP (KIT)

9

07000-15150

O-RING (KIT)

10

707-71-61111

PLUNGER

11

707-71-60250

PLUNGER

12

04260-00635

BALL

13

707-71-91270

CAP

14

07020-00900

FITTING,GREASE

15

707-27-16920

HEAD

16

198-63-94170

SEAL,DUST (KIT)

17

07179-13126

RING,SNAP

18

707-52-90850

BUSHING

19

707-51-11030

PACKING,ROD (KIT)

20

707-51-11630

RING,BUFFER (KIT)

21

707-35-91640

RING,BACK-UP (KIT)

22

07000-15150

O-RING (KIT)

23

01010-82085

BOLT

24

707-88-75310

WASHER

25

707-36-16380

PISTON

26

01310-01216

SCREW

27

707-44-16180

RING,PISTON (KIT)

28

707-39-16820

RING,WEAR (KIT)

29

707-44-16910

RING

30

07001-05100

RING,BACK-UP (KIT)

31

07000-15100

O-RING (KIT)

32

207-63-63771

TUBE

33

207-63-63180

TUBE

34

01435-01055

BOLT

35

07000-13035

O-RING (KIT)

36

707-88-95750

BRACKET

37

707-88-95740

BAND

38

707-88-95781

BRACKET

39

707-88-95770

BAND

40

01010-81240

BOLT

41

01643-51232

WASHER

42

07283-23442

CLIP

43

01643-31032

WASHER

44

01599-01011

NUT

45

07000-13032

O-RING

46

07378-11000

HEAD

47

07371-31049

FLANGE,SPLIT

48

07372-21035

BOLT

49

01643-51032

WASHER

K

707-99-67280

SERVICE KIT
