Запчасти Komatsu PC340LC-7K МОТОР ПОВОРОТА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

706-7K-01040

MOTOR ASS'Y

|1

706-7K-01011

MOTOR ASS'Y

|1

706-7K-03030

MOTOR SUB ASS'Y

|1

706-7K-03011

MOTOR SUB ASS'Y

1

706-7K-41610

SHAFT

2

706-77-43880

BEARING

3

706-7K-41810

SPACER

4

706-77-42051

SPRING

5

706-77-42041

SEAT

6

706-77-42890

BEARING

7

706-77-05010

SPACER KIT

|7

SPACER¤ 2.3MM

|7

SPACER¤ 2.5MM

|7

SPACER¤ 2.7MM

8

04064-06525

RING,SNAP

9

706-77-43950

SEAL,OIL

10

04065-07525

RING

11

706-7K-41210

BLOCK,CYLINDER

12

706-7K-41710

PLATE,VALVE

13

708-18-13230

PIN

14

706-7K-41120

SHAFT,CENTER

15

706-77-42130

RING,CENTER

16

706-7K-41140

SPRING

|17

706-7K-05010

RETAINER KIT

17

RETAINER

18

SCREW

19

706-7K-41160

PISTON SUB ASS'Y

20

706-7K-91340

PLATE

21

706-7K-91350

DISC

22

706-7K-91111

PISTON,BRAKE

23

07000-15230

O-RING

24

708-8H-15220

O-RING

25

706-7K-91360

SPRING
