Запчасти Komatsu PC340LC-7K BM ЦИЛИНДР ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC340LC-7K - BM ЦИЛИНДР ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
3
4
5
6
7
8
8
9
10
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
26
27
27
28
28
29
30
31
32
33
34
35
36
37
38
39
39
40
40
41
41
42
42

Артикул

Название

Примечание

Количество

G-1

707-01-XY310

CYLINDER GROUP,L.H. (FINAL COATING)

G-1

707-01-XA860

CYLINDER GROUP,L.H.

G-1

707-01-XY320

CYLINDER GROUP,R.H. (FINAL COATING)

G-1

707-01-XA870

CYLINDER GROUP,R.H.

|1

707-01-0A430

BOOM CYLINDER ASS'Y

1

707-13-14580

CYLINDER

2

707-76-90490

BUSHING

3

07145-00090

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

07043-00108

PLUG

6

707-58-10720

ROD

7

707-76-10290

BUSHING

8

07145-00100

SEAL,DUST (KIT)

9

707-71-34800

COLLAR

10

707-35-91420

RING,BACK-UP (KIT)

11

07000-15130

O-RING (KIT)

12

707-71-61090

PLUNGER

13

707-27-14930

HEAD

14

176-63-56170

SEAL,DUST (KIT)

15

07179-13114

RING,SNAP

16

707-52-90780

BUSHING

17

707-51-10030

PACKING,ROD (KIT)

18

707-51-10640

RING,BUFFER (KIT)

19

707-35-91420

RING,BACK-UP (KIT)

20

07000-15130

O-RING (KIT)

21

01010-81875

BOLT

22

707-41-11840

WASHER

23

707-36-14650

PISTON

24

01310-01216

SCREW

25

707-44-14180

RING,PISTON (KIT)

26

707-39-14110

RING,WEAR (KIT)

27

707-44-14910

RING

28

07001-05090

RING,BACK-UP (KIT)

29

07000-15090

O-RING (KIT)

30

707-86-11580

TUBE,L.H.

|30

707-86-11590

TUBE,R.H.

31

01435-01055

BOLT

32

07000-13035

O-RING (KIT)

33

207-63-54590

BRACKET

34

707-88-21370

BAND

35

01435-01235

BOLT

36

07283-23442

CLIP

37

01643-31032

WASHER

38

01599-01011

NUT

39

707-88-33040

CAP,(FOR SHIPPING)

40

07371-31049

FLANGE,SPLIT (FOR SHIPPING)

41

07372-21035

BOLT,(FOR SHIPPING)

42

01643-51032

WASHER,(FOR SHIPPING)

|K

707-99-58080

SERVICE KIT

Выбрано товаров: 49
