Запчасти Komatsu PC340LC-7K НАСОС АВТОМАТИЧ. ЗАПРАВКИ ТОПЛИВА РАЗНОЕ

1

20Y-04-K2081

PUMP ASS'Y,(SEE FIG.Y1040-01A0A)

|1

20Y-04-K2080

PUMP ASS'Y,(SEE FIG.Y1040-01A0)

2

207-04-K1390

BRACKET

|2

207-04-71530

BRACKET

3

01010-80620

BOLT

4

01643-30623

WASHER

5

01010-81235

BOLT

6

01643-31232

WASHER

7

20Y-04-K2351

HOSE

|7

20Y-04-K2350

HOSE

|7

207-04-71511

HOSE

|7

207-04-71510

HOSE

8

07289-00035

CLAMP

|8

07281-00419

CLAMP

9

20Y-04-K2450

VALVE ASS'Y

|9

20Y-04-K1570

VALVE ASS'Y

10

207-04-K1411

HOSE

|10

207-04-K1410

HOSE

|10

207-04-71521

HOSE

|10

207-04-71520

HOSE

11

07289-00035

CLAMP

|11

07281-00419

CLAMP

12

207-54-K3560

CASE

|12

207-54-73510

CASE

13

581-35-15430

GROMMET

14

08037-11025

GROMMET

15

01010-81220

BOLT

16

01643-31232

WASHER

17

01010-81235

BOLT

18

01643-31232

WASHER

19

09415-02512

CAP

20

207-54-73520

COVER

21

207-54-51381

HINGE (WELDED)

22

207-54-73530

SEAL

23

207-54-73540

SEAL

24

421-54-11372

LOCK ASS'Y (WELDED)

25

01010-81025

BOLT

26

01643-31032

WASHER

27

207-06-71540

SWITCH ASS'Y

28

01010-80616

BOLT

29

01643-30623

WASHER
