Запчасти Komatsu PC340LC-7K-E0 ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC340LC-7K-E0 - ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
3
4
5
6
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
28
29
29
30
30
31
31A
31B
31C
31D
32
33
34
35
36
36
37
38
39
40
41
41
42
42
43
43
44
44
45
46
47
48

Артикул

Название

Примечание

Количество

G-1

707-01-XZ980

CYLINDER GROUP,(FINAL COATING)

|1

707-01-0A450

ARM CYLINDER ASS'Y

1

707-13-16710

CYLINDER

2

707-76-10310

BUSHING

3

07145-00100

SEAL,DUST (KIT)

4

707-58-11360

ROD

5

707-76-10310

BUSHING

6

07145-00100

SEAL,DUST (KIT)

7

707-71-32800

COLLAR

8

707-35-91640

RING,BACK-UP (KIT)

9

07000-15150

O-RING (KIT)

10

707-71-61130

PLUNGER

11

707-71-70290

PLUNGER

12

04260-00635

BALL

13

707-71-91270

CAP

14

07020-00000

FITTING,GREASE

15

707-27-16920

HEAD

16

198-63-94170

SEAL,DUST (KIT)

17

07179-13126

RING,SNAP

18

707-52-90850

BUSHING

19

707-51-11030

PACKING,ROD (KIT)

20

707-51-11640

RING,BUFFER (KIT)

21

707-35-91640

RING,BACK-UP (KIT)

22

07000-15150

O-RING (KIT)

23

01010-82085

BOLT

24

707-88-75310

WASHER

25

707-36-16580

PISTON

26

01310-01216

SCREW

27

707-44-16180

RING,PISTON (KIT)

28

707-39-16120

RING,WEAR (KIT)

29

707-44-16910

RING

30

07001-05100

RING,BACK-UP (KIT)

31

07000-15100

O-RING (KIT)

31A

707-83-13010

VALVE

31B

07750-01628

SPRING

31C

707-87-14070

PLUG

31D

07002-12034

O-RING (KIT)

32

707-86-11600

TUBE

33

707-86-11610

BLOCK

34

01435-01055

BOLT

35

01435-01095

BOLT

36

07000-13035

O-RING (KIT)

37

707-88-22740

BRACKET

38

707-88-21380

BAND

39

207-63-64190

BRACKET

40

707-88-21390

BAND

41

01435-01235

BOLT

42

07283-23442

CLIP

43

01643-31032

WASHER

44

01599-01011

NUT

45

707-88-33040

CAP,(FOR SHIPPING)

46

07371-31049

FLANGE,SPLIT

47

07372-21035

BOLT,(FOR SHIPPING)

48

01643-51032

WASHER,(FOR SHIPPING)

|K

707-99-67090

SERVICE KIT

Выбрано товаров: 55
