Запчасти Komatsu PC340LC-6K-J КЛАПАН ПЕРЕГРУЗКИ (ДЛЯ ЦИЛИНДРА РУКОЯТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

702-21-08200

PILOT VALVE

1

BODY,VALVE

2

SPOOL

3

702-21-39410

CASE

4

RETAINER¤ 2.0MM

|4

RETAINER¤ 2.3MM

|4

RETAINER¤ 1.7MM

5

702-21-39430

FLANGE

6

702-21-39440

SPRING

7

702-21-39310

SPRING

8

709-62-31280

O-RING

9

702-21-39450

O-RING

10

702-21-38480

PLUG

11

01252-60830

BOLT

12

01252-60835

BOLT

13

01252-60820

BOLT

14

07000-03028

O-RING

15

709-94-92811

VALVE

16

709-94-91751

SPRING

17

700-93-11320

O-RING

18

700-93-11330

RING,BACK-UP

|19

709-70-76101

VALVE ASS'Y,RELIEF

19

SLEEVE

20

700-80-64220

RING

21

700-22-11410

O-RING

22

SEAL

23

POPPET

24

PISTON

25

SPRING

26

SEAL

27

07000-13024

O-RING

28

POPPET

29

O-RING

30

PLUG

31

NUT

32

NUT

33

SPRING

34

O-RING

35

SPACER

36

SEAT
