Запчасти Komatsu PC30UU-3 ОСНОВН. КЛАПАН (8-КЛАПАН) (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-18-14801

CONTROL VALVE

|1

723-18-14800

CONTROL VALVE

|1

723-18-13100

CONTROL VALVE

1

723-11-18330

VALVE

2

723-11-18340

SPRING

3

708-7R-11220

PLUG

4

07002-11223

O-RING

5

723-11-18170

VALVE

|5

723-11-18170

VALVE

6

723-11-18180

SPRING

|6

723-11-18180

SPRING

7

723-11-18190

PLUG

8

07002-11023

O-RING

9

723-11-19880

PLUG

10

07001-01009

RING,BACK-UP

|10

07001-01009

RING,BACK-UP

11

723-11-19841

SEAT

12

723-11-19960

O-RING

13

723-11-19851

VALVE

14

723-11-19871

RETAINER

15

723-11-19861

SPRING

16

723-11-18120

PLUG

17

07001-01007

RING,BACK-UP

18

723-11-19780

BLOCK

19

722-12-18240

O-RING

20

01252-60630

BOLT

21

723-11-29140

BLOCK

22

07000-12015

O-RING

23

07000-11007

O-RING

24

07000-11009

O-RING

|24

07000-11009

O-RING

25

01252-60640

BOLT

26

709-32-11930

PLUG

27

07002-11823

O-RING
