Запчасти Komatsu PC30R-8 ОСНОВН. КОНСТРУКЦИЯ (ОСНОВ.) (/) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20T-54-81411

BRACKET

2

112-860-1360

GROMMET

3

20U-54-23162

BOSS

4

01010-81025

BOLT

5

01643-31032

WASHER

6

20U-43-21121

SHAFT

7

01010-80616

BOLT

8

01643-30623

WASHER

9

195-61-34120

BEARING

10

20U-54-23360

SPRING

11

04052-10833

PIN,SNAP

12

04205-10822

PIN

13

01643-30823

WASHER

14

20U-43-21372

SPRING,LOOSE

|14

20U-43-21390

SPRING

15

04210-20500

YOKE

16

01580-10504

NUT

17

04205-10514

PIN

18

04052-10530

PIN,SNAP

19

20T-54-81420

BRACKET,L.H.

20

20T-54-81431

BRACKET,R.H.

|20

20T-910-8682

BRACKET,(FOR 1 ATTACHMENT AND PAT)

|20

20T-910-8681

BRACKET,(FOR 1 ATTACHMENT AND PAT)

20A

20T-910-8710

BAR,(FOR 1 ATTACHMENT AND PAT)

20B

01010-81025

BOLT,(FOR 1 ATTACHMENT AND PAT)

|20B

01010-81020

BOLT,(FOR AIR CON)

20C

01643-31032

WASHER,(FOR 1 ATTACHMENT AND PAT)

21

195-61-34120

BEARING

22

21W-43-31130

STOPPER

|22

21K-54-11310

STOPPER

23

01580-11210

NUT

24

20T-54-81440

BOSS

25

01010-81025

BOLT

26

01643-31032

WASHER

27

20T-54-81450

PIN

28

01010-80616

BOLT

29

01643-30623

WASHER

30

195-61-34120

BEARING

31

20U-54-23360

SPRING

32

04052-10833

PIN,SNAP

33

04205-10822

PIN

34

20U-43-21372

SPRING,LOOSE

|34

20U-43-21390

SPRING

35

04210-20500

YOKE

36

01580-10504

NUT

37

04205-10514

PIN

38

04052-10530

PIN,SNAP
