Запчасти Komatsu PC30R-8 СОЕДИНЕНИЕ КОВША (ДЛЯ QUICK ГИДРОМОЛОТ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

20S-870-0020

LINK ASS'Y

1

20S-870-1420

LINK

2

20S-70-11270

BUSHING

3

20S-870-1470

BUSHING

4

07145-00035

SEAL,DUST

5

07020-00675

FITTING,GREASE

6

07145-00050

SEAL,DUST

7

20S-870-1450

PIPE

8

198-43-15310

COLLAR¤ 10MM

9

01010-81230

BOLT

10

419-43-17920

WASHER

11

20S-870-1410

COUPLER

12

20S-870-1130

LINK,R.H.

13

20S-870-1140

LINK,L.H.

14

20S-70-71451

PIN

15

07020-00000

FITTING,GREASE

16

20S-70-71270

PLATE

17

01010-81635

BOLT

18

01643-31645

WASHER

19

20S-70-71491

SHIM¤ 2.5MM

20

20S-870-1160

PIN

21

20S-870-1170

PIN

22

20T-870-1190

PIN

23

20S-870-1440

PIN

24

20S-70-71270

PLATE

25

20S-70-81760

SPACER¤ 1.0MM

|25

416-46-12270

SHIM¤ 1.0MM

26

01010-81635

BOLT

27

01643-31645

WASHER

28

20S-870-1430

PIN

29

20S-870-1480

RETAINER

30

20S-870-1460

CAP

31

706-73-43610

SPRING

32

01010-81035

BOLT

33

01643-31032

WASHER

34

20T-870-1190

PIN
