Запчасти Komatsu PC30R-8 ГИДРОМОЛОТ РУКОЯТЬ (ГИДРОМОЛОТ) РАБОЧЕЕ ОБОРУДОВАНИЕ

Схема запчастей Komatsu PC30R-8 - ГИДРОМОЛОТ РУКОЯТЬ (ГИДРОМОЛОТ) РАБОЧЕЕ ОБОРУДОВАНИЕ
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
39
40
41
41
42
43
44

Артикул

Название

Примечание

Количество

|1

20S-870-1640

BREAKER

1

BK13011010

CYLINDER

2

BK13011020

PISTON

3

BK13011030

SLEEVE

4

BKE1022065

O-RING (KIT)

5

BKE3110048

U-PACKING (KIT)

6

BKE3120053

U-PACKING (KIT)

7

BKE1022070

O-RING (KIT)

8

BKE1012020

O-RING (KIT)

9

BK100106038

PLUG

10

BK21310160

VALVE

11

BK13013040

SLEEVE

12

BK13013055

PLUG

13

BKE1120040

O-RING (KIT)

14

BK10212040

RING,BACK-UP (KIT)

15

BK130130201

LINER,VALVE

16

BKE1120040

O-RING (KIT)

17

BK10212040

RING,BACK-UP (KIT)

18

BKK10616

PLUG,FLANGE

19

BKE1012018

O-RING (KIT)

20

BKA030A3699

BOLT

21

BKC810A016

WASHER

|22

BK13032000

CAP ASS'Y,(BACK)

22

BK13032010

CAP,BACK

23

BKE1022085

O-RING (KIT)

24

BK13012110

BODY,VALVE

25

BKR911101

VALVE (KIT)

26

BK13012120

CAP

27

BKE1022025

O-RING (KIT)

|28

BK130340001

CAP ASS'Y,(FRONT)

28

BK130340101

CAP,FRONT

29

BK13014110

BUSHING

30

BK13034210

BUSHING

31

BK21310450

FITTING,GREASE

32

BKD0510409

PIN,SPRING

33

BK21300189

PLUG

34

BK13014140

SLEEVE

35

BK13014310

PIN

36

BK13014320

PIN

|37

BK13012500

ROD ASS'Y,(SIDE)

37

BK13012510

ROD,SIDE

38

BK13012530

NUT

39

BKK10610

PLUG

40

BKK10618

PLUG

41

BKE10120125

O-RING

42

BKE1012020

O-RING

43

BKK10103A

PLUG

44

BKK10112A

PLUG

KIT

BK301Z-SK1

SERVICE KIT,BREAKER

Выбрано товаров: 49
