Запчасти Komatsu PC30R-8 MONO-СТРЕЛА (СТРЕЛА¤ РУКОЯТЬ ЛИНИЯ И ЛИНИЯ КОВША) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

20R-70-00410

BOOM ASS'Y

|1

20R-970-0130

BOOM ASS'Y,(FOR BREAKER)

1

BOOM

|1

BOOM,(FOR BREAKER)

2

20S-70-81140

BUSHING

3

07145-00045

SEAL

4

07020-00900

FITTING,GREASE

5

20R-62-82130

TUBE

6

20R-62-82141

TUBE

7

130-62-71350

CLAMP

8

01010-81020

BOLT

9

01643-31032

WASHER

10

20S-62-82211

PLATE

11

01010-81025

BOLT

12

01643-31032

WASHER

13

20S-62-82220

HOSE

14

20R-62-82170

HOSE

15

04434-52210

CLIP

16

07095-20213

CUSHION

17

01010-81020

BOLT

18

01643-31032

WASHER

19

08034-00834

BAND

20

20R-62-82111

TUBE

21

130-62-71350

CLAMP

22

01010-81020

BOLT

23

01643-31032

WASHER

24

20S-62-13140

CLAMP

25

01010-81020

BOLT

26

01643-31032

WASHER

27

20R-63-X2302

CYLINDER GROUP,BOOM

28

20S-70-71190

COVER

29

01010-81030

BOLT

30

01643-31032

WASHER

31

20T-70-71630

PAD

32

20T-70-71640

COLLAR

33

01010-80816

BOLT

34

01643-30823

WASHER

35

20R-63-X2314

CYLINDER GROUP,ARM
