Запчасти Komatsu PC30R-8 КАПОТ (COVER) ЧАСТИ КОРПУСА

Схема запчастей Komatsu PC30R-8 - КАПОТ (COVER) ЧАСТИ КОРПУСА
1
2
3
4
5
6
7
8
9
10
11
11
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
27
28
28
29
30
31
31
32

Артикул

Название

Примечание

Количество

|1

20T-54-82103

COVER ASS'Y

|1

20T-54-82102

COVER ASS'Y

|1

20T-54-82101

COVER ASS'Y

|1

20T-54-87172

COVER ASS'Y,(FOR TOPS CANOPY)

|1

20T-54-87171

COVER ASS'Y,(FOR TOPS CANOPY)

|1

20T-54-87170

COVER ASS'Y,(FOR TOPS CANOPY)

1

COVER

|1

COVER

|1

COVER

|1

COVER,(FOR TOPS CANOPY)

|1

COVER,(FOR TOPS CANOPY)

|1

COVER,(FOR TOPS CANOPY)

2

20T-54-82141

SHEET

3

20T-54-82682

SEAL

4

20T-54-82191

SHEET

5

20T-54-82261

PLATE

6

20T-54-82671

SHEET

7

20T-54-82630

SHEET

8

20T-54-82161

SHEET

9

01010-80820

BOLT

10

01643-30823

WASHER

11

04431-30000

PLATE

12

20T-54-82121

BRACKET

|12

20T-54-82120

BRACKET

13

01010-81020

BOLT

14

01643-31032

WASHER

15

20T-46-81350

SEAL

16

20T-54-82271

STAY

|16

20T-54-87151

STAY,(FOR TOPS CANOPY)

17

20T-54-82651

BAR

18

01641-21016

WASHER

19

04050-13020

PIN,COTTER

20

20B-54-12210

SPRING

21

01220-40406

SCREW

22

01641-20405

WASHER

23

01010-81235

BOLT

24

01643-31232

WASHER

25

20T-54-72660

CAP

26

20T-54-82251

COVER

27

01010-81030

BOLT

28

203-54-56970

WASHER

29

20T-46-81361

SEAL

30

20T-54-82660

SEAL

31

20T-46-81340

SEAL

32

20T-46-81370

SHEET

Выбрано товаров: 45
