Запчасти Komatsu PC30MRX-1 СЕРВИСНЫЙ КЛАПАН ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

723-11-00421

VALVE SUB ASS'Y

|$3

723-11-00361

VALVE SUB ASS'Y

1

BLOCK,VALVE

2

SPOOL

3

723-11-17450

PLUG

4

07002-10823

O-RING

5

723-11-17330

RETAINER

6

723-11-17351

RETAINER

7

723-11-17431

RETAINER

8

723-11-17360

BOLT

9

723-11-17341

SPRING

10

723-11-27290

CASE,SPRING

11

723-11-17410

CASE,SPRING

12

01252-60640

BOLT

13

01252-60620

BOLT

14

722-12-19120

O-RING

15

723-11-18170

VALVE

16

723-11-18190

PLUG

17

723-11-18180

SPRING

18

07002-11023

O-RING

19

VALVE

20

VALVE

21

723-11-16230

SPRING

22

723-11-15130

SPRING

23

PISTON

24

723-11-15110

PLUG

25

07002-11623

O-RING

26

07000-12100

O-RING

27

723-11-19110

O-RING

28

723-11-19150

RING

29

723-11-19130

O-RING

30

07000-11007

O-RING

|$34

723-10-16600

VALVE ASS'Y,SUCTION AND SAFETY

31

PISTON

32

SLEEVE

33

POPPET

34

SEAL

35

NUT

36

NUT

37

SPACER

38

PLUG

39

SEAL

40

SLEEVE

41

SPRING

42

POPPET

43

SPRING

44

07002-12034

O-RING

45

O-RING

46

01010-80865

BOLT

47

01643-50823

WASHER
