Запчасти Komatsu PC30MR-3 УПРАВЛЯЮЩ. КЛАПАН, 9-КЛАПАН (/) (№7-) УПРАВЛЯЮЩ. КЛАПАН, С АВТОМАТИЧ. DECELERATOR, ДЛЯ СТРАН ЕС ARRANGEMENT

|$0

723-19-16700

Valve, Control

1

723-11-17370

Case, Spring

1

723-11-01530

Case Subassembly

2

Case, Spring, Spring

3

Seat

4

Ball

5

Plug

6

07002-10823

O-ring

7

07000-11004

O-ring

8

722-12-19120

O-ring

8

723-11-01480

Case Subassembly

9

Case, Spring

10

722-12-19120

O-ring

11

702-21-54290

O-ring

12

Seat

13

Ball

14

Seat

15

Plug

16

723-11-19960

O-ring

17

723-11-37210

Case, Spring

18

07000-11008

O-ring

19

723-11-17361

Bolt

20

723-11-17353

Retainer

21

723-11-17330

Retainer

22

723-11-17341

Spring

23

722-12-19120

O-ring

24

723-11-37220

Case, Spring

24

723-11-01510

Case Subassembly

25

723-11-37230

Case, Spring

26

722-12-19120

O-ring

27

702-21-54290

O-ring

28

Seat

29

Ball

30

Seat

31

01252-60640

Bolt, Hexagon Socket Head

32

01252-60620

Bolt, Hexagon Socket Head

33

01252-60635

Bolt, Hexagon Socket Head

34

01252-60612

Bolt, Hexagon Socket Head
