Запчасти Komatsu PC308USLC-3E0 УПРАВЛЯЮЩ. КЛАПАН, ВНУТР. ЧАСТИ (/9) (№-) УПРАВЛЯЮЩ. КЛАПАН, -АКТУАТОР

|$0

723-47-25300

Valve Assembly

|$1

Valve Assembly

|$2

Valve Assembly

1

Block

2

702-21-55511

Spool

3

702-21-55640

Spring

4

702-21-55620

Plug

5

708-8H-11530

Plug

6

07002-11423

O-ring

7

702-21-55710

Seat

8

702-21-55720

Spring

9

04260-00793

Ball

10

07000-11009

O-ring

11

708-21-12541

Plug

12

723-40-71430

Valve

13

702-21-55460

Spring

14

702-21-55420

O-ring

15

702-21-55520

O-ring

16

702-21-55440

O-ring

17

702-21-53120

Filter

18

07000-12011

O-ring

19

01252-61040

Bolt, Hexagon Socket Head

20

01643-51032

Washer

21

702-21-55620

Plug

22

07002-11423

O-ring

23

708-8E-16160

Plug

24

07002-11023

O-ring

25

07000-12011

O-ring

26

708-21-12541

Plug

27

01010-61470

Bolt

28

01010-61460

Bolt

29

01643-31445

Washer, Flat

30

723-46-17560

Plate

31

01643-51032

Washer

32

01010-81040

Bolt
