Запчасти Komatsu PC308USLC-3E0 ГИДР. БАК. (№-) ГИДР. БАК., -АКТУАТОР

1

22U-60-27310

Tank

2

203-60-31100

Elbow Assembly

3

203-60-31160

Tube

4

02781-00628

Union

5

02896-11018

O-ring

6

07002-12434

O-ring

7

02782-10522

Elbow

8

02896-11015

O-ring

9

07002-12434

O-ring

10

02781-00315

Union

11

02896-11009

O-ring

12

07002-12034

O-ring

13

02781-0021D

Union

14

02896-11008

O-ring

15

07002-11423

O-ring

16

07040-11409

Plug

17

07002-11423

O-ring

18

207-60-71182

Element, Hydraulic Oil Filter

19

20Y-60-31140

Strainer

20

20Y-60-31131

Valve Assembly

21

20Y-60-21240

Spring

22

22U-60-21232

Cover

23

07000-15195

O-ring

24

01010-81230

Bolt

25

01643-31232

Washer

|$25

22U-60-81520

Strainer Assembly

26

22U-60-81530

Rod

27

20Y-60-21320

Holder

28

12R-60-11230

Spring

29

22B-60-11160

Strainer

30

22U-60-27131

Cover

31

07000-15160

O-ring

32

01010-81230

Bolt

33

01643-31232

Washer

34

17A-60-11310

Cap Assembly

35

20Y-60-21470

Element

36

208-60-71180

Filler Neck

37

20Y-60-21340

Gasket

38

01252-70516

Bolt

39

01601-20513

Washer

40

07285-00155

Clip

41

07270-61417

Tube

42

04434-51812

Clip

43

01010-81220

Bolt

44

01643-31232

Washer

45

205-00-73360

Plate, Operating
